1.Trapezoid shape PCB design ensures seamless jointing&high uniformity.
Special design for each utility models Wide viewing angel of 360°;
2.Uniform sampling point: support uniform technology to display the image without distortion.
3.Flexible control: compatible with asynchrony,support offline and online methods
4.Convenient installation: as a complete system,support installation, hoisting, embedded
installation, etc
5.Convenient maintenance: support pre-maintenance and post-maintenance;
1.Trapezoid shape PCB design ensures seamless jointing&high uniformity.
Special design for each utility models Wide viewing angel of 360°;
2.Uniform sampling point: support uniform technology to display the image without distortion.
3.Flexible control: compatible with asynchrony,support offline and online methods
4.Convenient installation: as a complete system,support installation, hoisting, embedded
installation, etc
5.Convenient maintenance: support pre-maintenance and post-maintenance;
| Usage | indoor | indoor | indoor | indoor |
| Pixel Pitch | 1.8mm | 2.5mm | 3mm | 4mm |
| LED Type | SMD1515 | SMD2121 | SMD2121 | SMD2121 |
| Physical Density | 284000 dot/m² | 160000 dot/m² | 111111 dot/m² | 62500 dot/m² |
| Scanning Mode | 1/43 | 1/32 | 1/32 | 1/16. |
| Spherical diameter | 0.8m/1m/1.2m/1.5m/1.8m/2m/2.5m/3m/4m/5m/6m(Arbitrary diameter) | |||
| Panel Material | iron | |||
| Panel Weight | 30kg/㎡ | |||
| Panel Flatness | ≤0.10 mm | |||
| Brightness | ≥1200 cd/㎡ | |||
| Viewing Angle | ≥140° (H) / 140° (V) | |||
| Refresh Rate | 3840Hz | |||
| Input Voltage AC | 110~220V | |||
| Max. Power Consumption | ≤700 w/㎡ | |||
| Ave. Power Consumption | ≤300 w/㎡ | |||
| Working Temperature | -10℃～+40℃ | |||
| Working Humidity | 10%～90%RH | |||
| Lifespan | ≥100,000 hrs | |||
| Brand | Shenzhen King Visionled | |||
At here, it’s all about giving the clients thebest quality products.
